ProtoFPV PROTO35 Gauntlet frame kit- stealth black.
No hype, just pure 3.5" performance. 😉
P35G is a top-tier 3.5" frame, built with lightweight T700 carbon fiber and locked in with titanium screws. Engineered for minimal vibration and resonance, it delivers sharp, precise tuning for killer performance. No props in view means your footage stays clean and cinematic plus the camera remains protected with it's thick carbon fiber camera cage. P35G rips through the air with a roar like a mini F1 race car and is DJI O4 Pro ready or compatible with most 19-20mm camera and VTX systems in the market today.
Highlights:
1) Minimal to no props in view
2) Lightweight sub250 while still using thick hardware from a 5" tank
3) Full 2.5mm thick carbon fiber camera cage - Up to 45 degree tilt
4) TPU60A pro camera inserts reduce jello or vibration effects to the camera
5) Tune it up! Ultra rigid frame with low vibration and resonance characteristics
6) Every carbon fiber piece is low cost and replaceable
-
RECOMMENDED PARTS
This frame has only been tested and tuned with the highest quality components
RECOMMENDED PARTS (Not Included)
Build Specifications w/Links:
Motors: DeepspaceFPV 1505-4000kv motors
Power: 4SMOTORS 6S: DEEPSPACEFV Aether 2006-2550KV
Motors 6S: AxisFlying FPV C206 2006-2750KV
AIO: GepRC Taker F722 45A AIO.Mini Stack: HAKRC 40A MINIF7 STACK.
Or any 35A equivalent will do
Props: Avan Scimitar 3.5x2.8x3 PROPS
VTX: O4 AU PRO
Receiver: TBS Crossfire nano RX
GPS: Nano GM10 GPS
Weight: 17g
7) 12 supporting TPU prints included
8) 51 titanium screws included
9) 9x9 or 12x12 motor configuration. Build it 4S, 6S, however you like!
Proudly designed, 3D printed, and shipped from Vancouver, British Columbia, Canada 🍁
INCLUDES
T700 Carbon Fiber Plates
x1 Top plate
x1 Arm cap F
x1 Arm cap R
x1 Arm 1
x1 Arm 2
x1 Arm 3
x1 Arm 4
x1 Camera cage set
x1 Base plate
3D Prints
x1 Protostrap MS (medium/small sized batteries)
x1 Dual antenna mount
x1 Nano GPS tray
x1 RX antenna holder set
x1 LED light holder
x1 Feet Set (4 pc)
x1 Cam dampener set L&R
Hardware
Titanium M3 x 5 top plate |
6 |
Titanium M3 x 10 bottom plate arms |
4 |
M2x22 Stand off |
2 |
M3x24 Stand off |
1 |
M3x20 Stand off |
4 |
Titanium M2 x 5 camera/vtx/acm |
9 |
Titanium M2 x 6 cage |
4 |
Titanium M2 x 7 motors, props, arm caps |
28 |
M2 x 22 screw stack/aio |
4 |
M2 washer (camera) |
4 |
M2 nylon nut (Aio or VTX) |
12 |
M2x5 nylon Stand off (VTX Spacer) |
4 |
Single LED WS2812 |
1 |
Spare 30AWG wiring |
1 |
Zip Tie |
4 |
