HAKRC 40A miniF7 Stack

Regular price $83.99

Shipping calculated at checkout.

HAKRC 40A miniF7 Stack.

*REPLACEMENT STACK FOR DeepSpaceFPV SEEKER-3 BNF

HAKRC 40A MiniF7 Stack is equipped with BLHeli-32 40A four-in-one ESC and F722 flight control, Installation hole spacing of 20 * 20mm.F722 flight controller is equipped with 6 serial ports,ICM-42688 IMU,OSD,F.Port and many other functions!Built-in plug-in allows you to easily connect to the DJI O3/O4 Air Unit.I ntegrated 16Mb black box, barometer, upgraded Type-C USB interface, greatly improve socket life and reduce the risk of poor contact. Supports various receivers including SBUS,ELRS, PPM, CRSF, DSMX, iBus, DSM2, etc.

HAKRC 40A MiniF7 Stack is equipped with BLHeli-32 40A four-in-one ESC and F722 flight control, Installation hole spacing of 20 * 20mm.F722 flight controller is equipped with 6 serial ports,ICM-42688 IMU,OSD,F.Port and many other functions!Built-in plug-in allows you to easily connect to the DJI O3/O4 Air Unit.Integrated 16Mb black box, barometer, upgraded Type-C USB interface, greatly improve socket life and reduce the risk of poor contact. Supports various receivers including SBUS,ELRS, PPM, CRSF, DSMX, iBus, DSM2, etc.

  F722 FC Specifications:



Size: 29 * 39mm (20mm-20mm mounting hole)

package size: 64 * 64 * 35mm

input voltage: 2S-6S LIPO

product net weight: 6g

package weight: 37g

CPU: STM32F405RET6

IMU: ICM42688 dual gyroscope

OSD: AT7456E

barometer: Integrated

Black Box: 16MB

EC: 5V/2A

BEC: 10V/2A

LED: support external adjustable LED

sensor: built-in current sensor

firmware version: HAKRCF722V2

receiver: Frsky/Futaba/Flysky/TBS Crossfire/DSMX: DSM2 receiver

  BLHeli_32 40A ESC Specifications:



Size: 44 * 44mm (20mm-20mm mounting hole)

Packaging size: 64 * 64 * 35mm

Net weight of product: 6g

Packaging weight: 41g

Input voltage: 2S-6S Lipo

Galvanometer ratio: 300

Continuous current: 40A

Peak current: 45A

Supporting the transmission of electrical dispatch telemetry data maps

Electric adjustment firmware: HAKRC-40-K42_ Multi_ 32_ 8. Hex

Protocol support: PWM, Oneshot125, Oneshot42, Multispot, Dshot150, Dshot300, Dshot600
