We took everything great about the grinder motors and made them better, thicker where it counts, stronger materials and a shiny gold top to show the bando you mean bussiness
SPECIFICATIONS:
- Stator Size (Diameter): 22mm*7mm
- Kv: 1750kv
- Magnets N52SH: Curved
- Windings: 10.5 turn DLRK
- Shaft Length (mm): 11.5mm
- Shaft Diameter (mm): 3mm
- Shaft material: Steel
- Bearing: NSK693
- Weight (With Wires) (g): 34.8g34.8g
- Cells (Lipo): 4S-6S
- Max Current (A): 45A
- Max Burst Current (A): 50A
- Internal Resistance (Rm): 66Ω
- Wire Spec (AWG): 20#
- Base Mounting Pattern: 16x16mm
- Base Mounting Thread: M3 Thread
- Motor Overall Dimensions: φ27.5mm*18.8mm
- Motor Name: Grinder V3 KV1750
