2RAW Afterburner 5 O3 6S HD BNF

Regular price $729.99

Shipping calculated at checkout.

2RAW Afterburner 5 O3 6S HD BNF with TBS RX. with GPS.

2RAW Afterburner 5

Description:

Afterburner - The Performance 5inch by 2RAW and iFlight

NOT A FREESTYLE DRONE - Afterburner is designed for professional pilots who use their FPV drones for cinematic work, this drone is not designed around being crashed into concrete and coming out fine. The drone is designed around aerodynamics and balance.

Highlights:

Smallest Footprint

Afterburner has a 20% smaller footprint than traditional 5inch freestyle frames, this allows for easier transportation as well as increased agility and less drag - meaning better all round performance.

Aero Shell

The aeroshell controls the airflow around the body and within the drone.  As the speed of the drone increases the aero shell acts as an air divider, preventing air from hitting the flat top plate. The shell also helps to shield the electronics from dirt and moisture so you can have more confidence in critical situations.

Advanced Truss Arms

The star design combined with the trusses ensures great stiffness while keeping the weight down, and perfect balance, delivering exceptional results when it comes to filming with buttery footage.

Bottom Mount Battery

Inspired from FPV racers, we took a bottom mount battery approach, this allows the battery to cause minimal drag possible and completely clears the top of the drone to allow for the Gopro mounting as well as clear line of sight for the GPS. Afterburner was built for the cinema pilot! The central battery also allows the CG to remain close to the middle of the body allowing for improved agility in the air.

No Prop in view with Gopro

In 16:9 the GoPro has no props in the view from 5 degrees all the way to 60 degrees.

DJI O3 HD Air Unit Low-Latency Digital Transmission

Up to 10 km video transmission range, enjoy a crisp and smooth real-time view in your goggles, even in environments with interference. (Source DJI)

4K Stabilized Video with 155° Ultra-Wide Angle

Together with high-grade imaging performance, it delivers exceptional visuals that will keep your audience on the edge of their seats. (Source DJI)

Specifications

Product Name: Afterburner 5 O3 6S HD

FC: BLITZ F7 Flight Controller

ESC: BLITZ E55 4-IN-1 2-6S 55A ESC

Video Transmission: DJI O3 Air Unit

Geometry: X-Frame

Frame: 210 mm wheelbase

Motor: XING2 2207 1750KV motors

Prop: GEMFAN 5.1X3.6X3 propellers

Weight: 472±7g (Without Battery)

Dimensions (L×W×H):148x148x64mm

Max Speed: 160km/h

Maximum Takeoff Altitude: 7000 m

Max Hover Time: Approx. 11mins with 6S Lipo 1400mAh battery W/O Load

Operating Temperature Range: -10° to 40° C

Antennas: Single Antennas

GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Aerodynamic body allows for minimal surface drag

2RAW After Burner


CNC Action Camera Mount

CNC action camera mount for extra strength and minimal camera wobble, [5° -60° 16:9 no props in view]


Truss Structure

Vertical arms allow for lowest possible weight, while maintaining maximum strength and resonance performance


Smallest Footprint

20% small footprint then traditional X 5inch drones


Star shape

Innovative, True X symmetrical Star shape for perfect balance on all axis


Integrated GPS

Integrated GPS for optimal satellite signal at all time, maximising reliability

Smooth & Stable Tune

All our Drone come with a next level tunes. Each tune is factory optimised for
payload, components and external forces.

Aero ShellThe aeroshell doesn't only make Afterburner look unique but was engineered with aerodynamics in mind. It controls the airflow around the body and within the drone. As the speed of the drone increases the aero shell acts as an air divider, preventing air from hitting the flat top plate. The shell also helps to shield the electronics from dirt and moisture so you can have more confidence in critical situations.
Advanced Truss ArmsOver several months the team experimented with various different arm designs made out of flat carbon. Several concepts and different truss structures were tested until we found the optimal arms. The star designed combine with the trusses ensure great stiffness while keeping the weight down, and perfect balance, delivering exceptional results when it comes to filming with buttery footage.
Bottom Mount BatteryInspired from FPV racers, we took a bottom mount battery approach, this allows the battery to cause minimal drag possible and completely clears the top of the drone to allow for the Gopro mounting as well as clear line of sight for the GPS. In 16:9 the Gopro has no props in view from 5 degrees all the way to 60 degrees. Afterburner was built for the cinema pilot! The central battery also allows the CG to remain close to the middle of the body allowing for improved agility in the air.
Lowest Resonance - Highest Performance

Our team does a lot of experimenting with different shapes and material.
T700 Toray Twill weave Carbon Fibre means you are guaranteed to be
getting the very best quality material.
