MAMBA F722SAPP FC+ F50PRO 3-6S FLIGHT CONTROLLER STACK with Speedybee and Bluetooth/wifi built-in.

DIATONE INNOVATIONS

NOTICE：

PHOTOS IS FOR REFERENCE .

SUBSEQUENT VERSIONS WILL CANCEL THE ESC HEAT SINK.

MAMBA F722S F50PRO 3-6S FLIGHT CONTROLLER STACK

FIRMWARE TARGET ： MAMBA F722 （LEGACY）

Note：Since STM32F722 heat large ， please leave at least 5mm interspace at both sides of the FC with nothing covered to make sure a good air circulation.

FC Specifications

MCU: 216MHz STM32F722RET6 32BIT
IMU: MPU6000
Baro: No
OSD: BF OSD
Blackbox: 16M Flash Memory
Uarts: 6Set
ESC Soft: Dshot300/600/1200
ESC Telemetry: RX6
LED: Blue&Orange for FC Status,, Green 9V, White 5V, Red 3.3V

Controller: 4 Set 2812 LED

Bluetooth: SpeedyBee APP

Smartaudio: Yes
RSSI: Yes
Buzz: Yes

Input: 3~6S Lipo (12.6~25V)
VTS Protection: Yes
BEC: 5V 2.5A & 9V 2A (Max 3A)

ESC Specifications

F50PRO

INPUT VOLTAGE: 3~6S Lipo (12.6V~25V)

CONTINUE CURRENT: 50A×4

BURST CURRENT: 60A (10S)

BEC: NO

ESC Dshot300/600/1200

MOUNTING: 30.5mm/M3

Supply : Panasonic High Frequency 470uF/35V



FC Firmware
BetaFlight
Target: MAMBA F722
Download Link

Mounting: 30.5×30.5mm,Φ3
Dimensions:
Weight: 22g


Including
1×FC MAMBA F722S STACK

About BT SpeedyBee Function：
